The 6262 aluminum rod is renowned for its exceptional strength, ease of machining, and corrosion resistance. The addition of bismuth and lead significantly enhances its machining quality, resulting in smooth and clean-cut chips.
This alloy is very easy to machine, making it ideal for screw machines and various machining needs.
Specifications of 6262 aluminum bars
- EN 573,EN 754,EN 755
- ASTM B210,ASTM B210,ASTM B467
- QQ-A-225/10
- AMS 4150
- MIL-A-8625
Popular size range for 6262 aluminum bars
We offer 6262 aluminum rods in various standard and special tempers.
For machining applications, the 6262 alloy is available in a variety of round bars, square bars, and hex bars.Quick Quote
6262 aluminum round bar size
| Description | Temper | Diameter | Length |
| 0.25" 6262 Aluminum Round Bar | T9 | 0.25 " | 1-6m(Cuttable) |
| 0.375" 6262 Aluminum Round Bar | T9 | 0.375 " | 1-6m(Cuttable) |
| 0.5" 6262 Aluminum Round Bar | T9 | 0.5" | 1-6m(Cuttable) |
| 0.5625" 6262 Aluminum Round Bar | T9 | 0.5625" | 1-6m(Cuttable) |
| 0.625" 6262 Aluminum Round Bar | T6511 | 0.625" | 1-6m(Cuttable) |
| 0.625" Aluminum Round Bar | T9 | 0.625" | 1-6m(Cuttable) |
| 0.75" Aluminum Round Bar | T6511 | 0.75" | 1-6m(Cuttable) |
| 0.75" Aluminum Round Bar | T9 | 0.75" | 1-6m(Cuttable) |
| 0.8125" 6262 Aluminum Round Bar | T9 | 0.8125" | 1-6m(Cuttable) |
| 0.875" Aluminum Round Bar | T6511 | 0.875" | 1-6m(Cuttable) |
| 0.875" Aluminum Round Bar | T9 | 0.875" | 1-6m(Cuttable) |
| 1" Aluminum Round Bar | T6511 | 1" | 1-6m(Cuttable) |
| 1" Aluminum Round Bar | T9 | 1" | 1-6m(Cuttable) |
| 1.1875" 6262 Aluminum Round Bar | T9 | 1.1875" | 1-6m(Cuttable) |
| 1.25" Aluminum Round Bar | T6511 | 1.25" | 1-6m(Cuttable) |
| 1.25" Aluminum Round Bar | T9 | 1.25" | 1-6m(Cuttable) |
| 1.3125" 6262 Aluminum Round Bar | T9 | 1.3125" | 1-6m(Cuttable) |
| 1.375" Aluminum Round Bar | T6511 | 1.375" | 1-6m(Cuttable) |
| 1.375" Aluminum Round Bar | T9 | 1.375" | 1-6m(Cuttable) |
| 1.5" Aluminum Round Bar | T6511 | 1.5" | 1-6m(Cuttable) |
| 1.5" Aluminum Round Bar | T9 | 1.5" | 1-6m(Cuttable) |
| 1.5625" 6262 Aluminum Round Bar | T9 | 1.5625" | 1-6m(Cuttable) |
| 1.75" 6262 Aluminum Round Bar | T9 | 1.75" | 1-6m(Cuttable) |
| 1.875" 6262 Aluminum Round Bar | T9 | 1.875" | 1-6m(Cuttable) |
| 2" Aluminum Round Bar | T6511 | 2" | 1-6m(Cuttable) |
| 2.375" 6262 Aluminum Round Bar | T9 | 2.375" | 1-6m(Cuttable) |
| 2.5" 6262 Aluminum Round Bar | T9 | 2.5" | 1-6m(Cuttable) |
| 2.75" 6262 Aluminum Round Bar | T9 | 2.75" | 1-6m(Cuttable) |
| 3" 6262 Aluminum Round Bar | T9 | 3" | 1-6m(Cuttable) |
6262 aluminum hexagonal bar dimensions
| Description | Temper | Side Length | Length |
| 0.75" 6262 Aluminum Hex Bar | T6511 | 0.75" | 1-6m(Cuttable) |
| 0.875" 6262 Aluminum Hex Bar | T6511 | 0.875" | 1-6m(Cuttable) |
| 1" 6262 Aluminum Hex Bar | T6511 | 1" | 1-6m(Cuttable) |
| 1.125" 6262 Aluminum Hex Bar | T6511 | 1.125" | 1-6m(Cuttable) |
Sizes of 6262 aluminum square bars
- Temper: T6, T6511, T8, T9
- Imperial Side Lengths: 0.125" - 8"
- Metric Side Lengths: 3mm - 150mm
- Length: 1-6 m (Cuttable)
Chemical elements of 6262 aluminum bar
| Chemical Element | % Present |
| Si | 0.40 - 0.80 |
| Fe | 0.0 - 0.70 |
| Cu | 0.15 - 1.40 |
| Mn | 0.0 - 0.15 |
| Mg | 0.80 - 1.20 |
| Cr | 0.04 - 0.14 |
| Zn | 0.0 - 0.25 |
| Ti | 0.0 - 0.15 |
| Bi | 0.40 - 0.70 |
| Pb | 0.40 - 0.70 |
| Other (Each) | 0.05 max |
| Others (Total) | 0.15 max |
| Aluminium (Al) | Balance |
Physical properties of 6262 aluminum bar
| Physical Property | Value |
| Density | 2.71 g/cm³ |
| Melting Point | 582 °C |
| Thermal Expansion | 23.4 x10^-6 /K |
| Modulus of Elasticity | 68.3 GPa |
| Shear Modulus | 26 GPa |
| Thermal Conductivity | 172 W/m.K |
| Electrical Resistivity | 0.039 x10^-6 Ω . |
Mechanical properties of 6262 aluminum bar
Mechanical properties of 6262 extruded aluminum bar
| Temper | Dimension (mm) | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HB) |
| T6 | ≤ 200 | Min. 260 | Min. 240 | 10 | 75 |
Mechanical properties of 6262 cold drawn aluminum bar
| Temper | Dimension (mm) | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HB) |
| T6 | ≤ 80 | Min. 290 | Min. 240 | 10 | 85 |
| T8 | ≤ 50 | Min. 345 | Min. 315 | 4 | - |
| T9 | ≤ 50 | Min. 360 | Min. 330 | 4 | - |
Advantages of 6262 aluminum bar
- High Strength: 6262 aluminum rods offer excellent mechanical strength, making them suitable for high-strength applications.
- Easy to Machine: 6262 aluminum rods have outstanding machinability, allowing for quick processing and easy shaping into various complex forms.
- Corrosion Resistance: 6262 aluminum rods can withstand harsh environmental conditions while maintaining material integrity.
- Thermal Stability: 6262 aluminum rods exhibit minimal thermal expansion and contraction, ensuring dimensional stability even in fluctuating temperature environments.
- Lightweight yet Strong: 6262 aluminum rods strike a good balance between strength and lightweight characteristics, making them ideal for applications where weight reduction is crucial.
Applications of 6262 aluminum bar
- Aerospace: Used in the manufacture of fuselages, fuselage components, landing gear parts, wingtips, and engine nacelles.
- Automotive: Applied in brake discs and hubs, hydraulic valve blocks, and air conditioning components.
- Engineering and Manufacturing: Utilized for gears, bearings, bushings, and various fasteners.
- Hardware Components: Employed in camera parts, couplings, marine fittings, hinge pins, knobs, nuts, tubing fittings, fixture components, valves, and their parts.
Machining recommendations for 6262 aluminum bar
Machinability: This alloy offers excellent machinability, suitable for high-speed steel or carbide tools, allowing for smooth surface finishes.
Cutting Lubrication: For heavy cutting, it is recommended to use oil lubricants to enhance machining effectiveness and tool life. Light cutting operations can be performed dry to maintain efficiency.
Anodizing: Due to its outstanding surface finish, anodizing after machining is straightforward and helps improve corrosion resistance and appearance.
Cold Working Capability: Cold working is poor in T9 temper, while T6511, T6, and T651 tempers exhibit moderate cold working characteristics.
Weldability of 6262 aluminum bar
Weldability: 6262 aluminum alloy has good weldability, suitable for all welding methods, including gas, arc, and resistance welding.
Welding Performance Comparison: Compared to alloy 2011, the welding and brazing characteristics of 6262 are significantly improved, though still lower than those of alloy 6061.
Welding Effects: As a heat-treatable alloy, the heat generated during welding or brazing may reduce its strength in the T6 temper.
Brazing Connections: This alloy can also be joined through brazing, providing flexible connection options.
Quality inspection report — traceable
Our products undergo strict quality control, providing a full set of quality inspection reports.
- Ultrasonic Testing: Ensures no internal defects.
- Chemical Composition Analysis: Complies with industry standards.
- Mechanical Property Testing: Validates product strength.
- Non-Destructive Testing: Thoroughly checks for potential issues.
- Visual Inspection: Striving for excellence.
- Traceability Records: Fully traceable throughout the process.
Related products of 6262 aluminum bar
Alloy 6262, with its excellent corrosion resistance and machinability, as well as outstanding performance in anodizing reactions, clearly outperforms alloy 2011, making it an ideal substitute for 2011.
6262 aluminum alloy is similar to 6162, but due to its broader applications and lead content, it offers unique machining advantages, making it more competitive in various applications.
