5052 aluminum bar is a widely used aluminum alloy product, mainly composed of magnesium and chromium as the main alloying elements, with excellent corrosion resistance, medium strength and good weldability.
It is often used in marine engineering, chemical equipment, building materials and other fields. The versatility of 5052 aluminum bar makes it an ideal choice for multiple industrial fields.
MASTAR 5052 aluminum bar rod product introduction
Stock product types: 5052 cold drawn bar; 5052 aluminum alloy extruded bar; 5052 hot rolled bar; 5052 aluminum rod; 5052 aluminum flat bar
Equivalent Product Names: UNS A95052, ISO AIMg2.5, Aluminium 5052, AA5052, Al5052
Aluminum bar size range: 5052 aluminum round bar (5-600mm); 5052 aluminum flat bar (2-200mm); 5052 aluminum square bar, hexagonal bar opposite side distance (5-200mm)
Length: 1-6m; can be cut to any length.
Surface treatment: mill finish, anodized, bright, black, polished …
MASTAR 5052 aluminum cold drawn bar
- Temper: O, H14, H18, H32, H34
- Production executable standards:
- ASTM B211 / ASME SB211
- AMS-QQ-A-225/7
| 5052 aluminum alloy cold drawn bar product mechanical properties reference table | |||||
| Temper | Diameter or thickness mm | Ultimate Tensile Strength R m /MPa | Yield Tensile Strength Rp0.2/MPa | Elongation at Break % | |
| A | A 50mm | ||||
| O | ≤50 | 170-220 | ≥65 | ≥22 | ≥25 |
| H14 | ≤30 | ≥235 | ≥180 | ≥5 | - |
| H18 | ≤10 | ≥265 | ≥220 | ≥6 | - |
| F | ≤100 | - | - | - | - |
- Dimensional accuracy: the cold drawing process ensures high-precision dimensions and reduces tolerances.
- Surface quality: the surface is smooth and almost no subsequent processing is required, which is suitable for applications with strict requirements on appearance.
- Higher strength: it has higher strength and is suitable for parts bearing medium loads.
MASTAR 5052 aluminum alloy extruded rod
- Temper: H112 O
- Production executable standards:
- ASTM B221 / ASME SB221
| 5052 aluminum alloy extruded rod mechanical properties reference table | |||||
| Temper | Diameter (square rod, Hexagonal rod finger incision Circle diameter) /mm | Ultimate Tensile Strength R m /MPa | Yield Tensile Strength R p0.2/MPa | Elongation at Break % | |
| A(%) | A 50mm (%) | ||||
| H112 | ≤250 | ≥170 | ≥70 | - | - |
| O | 170-230 | ≥70 | ≥17 | ≥15 | |
- Shape flexibility: the extrusion process can produce a variety of complex cross-sections to meet different design requirements.
- Uniform performance: good surface finish and uniform mechanical properties make it stable in structural applications.
- Higher strength: suitable for applications requiring high strength and structural stability, such as frames and supports.
MASTAR 5052 hot rolled bar
- The 5052 aluminum rod produced by hot rolling at high temperature can improve the ductility, strength and toughness of the aluminum rod, while reducing internal stress and improving the overall mechanical properties of the material.
- Production executable standards:
- AMS 4114 / ISO AlMg2,5
- AMS 4102/ISO Al99.0cu
- Dimensional stability: the high temperature hot rolling process reduces internal stress and improves dimensional stability and consistency.
- Ductility: hot rolling increases the ductility of aluminum bars, making them easier to process into large sizes and complex shapes.
MASTAR 5052 aluminum rod
- Compared with 5052 aluminum round bar, 5052 aluminum rod usually refers to a cylindrical aluminum material with a smaller diameter, ranging from a few millimeters to tens of millimeters. Due to its slender shape, aluminum rods are often used in applications that require a circular cross-section, such as precision mechanical parts and shaft components.
MASTAR 5052 aluminum flat bar
- 5052 aluminum flat bar has a flat rectangular or square cross-section, suitable for manufacturing flat components and structural parts. It provides high strength and good bending resistance, and can withstand large loads. In terms of processing, it is easy to cut, bend and weld, which is convenient for application in various applications.
MASTAR 5052 aluminum bar other hot selling products
- 5052 Aluminum Round Bar
Diameter 5-600mm
- 5052 Aluminum Square Bar
Distance between edges: 5-200mm
- 5052 Aluminum Hexagonal Rod
Distance between edges: 5-200mm
- 5052 Half Round Bar
- 5052 Bright Stick
- More 5052 aluminum bar customization
5052 aluminum rod chemical composition
| 5052 aluminum bar chemical composition reference table | |
| Aluminum (Al) | 95.8 to 97.7 |
| Magnesium (Mg) | 2.2 to 2.8 |
| Chromium (Cr) | 0.15 to 0.35 |
| Iron (Fe) | 0 to 0.4 |
| Silicon (Si) | 0 to 0.25 |
| Manganese (Mn) | 0 to 0.1 |
| Zinc (Zn) | 0 to 0.1 |
| Copper (Cu) | 0 to 0.1 |
| Residuals | 0 to 0.15 |
Corrosion resistance and weldability of MASTAR 5052 aluminum rod
MASTAR 5052 Aluminum Round Bar is a high quality aluminum bar made of 5052 aluminum alloy, mainly magnesium as the main alloying element. Corrosion resistance and weldability are the two main features of 5052 aluminum bar.
Corrosion resistance
- Seawater corrosion resistance: 5052 aluminum alloy can maintain good corrosion resistance in seawater, so MASTAR 5052 aluminum rods are often used in marine engineering, ship structures and other environments.
- Resistance to industrial atmospheric corrosion: In an environment exposed to acidic, alkaline or humid air, 5052 aluminum alloy can still maintain a high level of corrosion resistance, so it is suitable for chemical equipment, storage tanks, etc.
- Surface protection layer: The oxide film of 5052 aluminum alloy can spontaneously form a protective oxide layer in most environments, which makes MASTAR 5052 aluminum rods do not require additional anti-corrosion treatment in a variety of corrosive environments.
Solderability
- Welding process compatibility: MASTAR 5052 aluminum rod can be welded by common welding methods such as MIG (Metal Inert Gas Welding), TIG (Tungsten Inert Gas Welding), etc. The welding process is smooth and easy to operate.
- Strength and corrosion resistance after welding: After welding, 5052 aluminum alloy can maintain good strength under appropriate welding conditions, and its corrosion resistance will not be significantly reduced, ensuring the long-term durability of the welded parts.
- Stable performance of heat-affected zone: During the welding process, the heat-affected zone (HAZ) of 5052 aluminum alloy shows good stability, and there will be no significant hardness reduction or crack formation in the heat-affected zone after welding.
MASTAR 5052 aluminum bar cooperation areas
Marine engineering: used in ship structures, offshore platforms, etc. due to its excellent resistance to seawater corrosion.
Chemical equipment: suitable for storage tanks, pipelines and other equipment, able to resist corrosion from acidic and alkaline media.
Transportation: Used in automobile fuel tanks, truck bodies, etc. due to its lightweight and corrosion-resistant properties.
Construction engineering: used for curtain walls, roofs and other building materials, with good weather resistance and aesthetics.
Electronic equipment: used in electrical housings, radiators, etc. due to its good thermal conductivity and machinability.
Food processing equipment: Suitable for food containers and processing equipment, ensuring non-toxic, odorless and corrosion-resistant.
5052 aluminum rod buying guide
1.How to calculate the weight of 5052 aluminum bars when purchasing
When purchasing aluminum bars on MASTAR, you can click [Calculator Service] to easily calculate the weight of 5052 aluminum bars.
2.What is the tolerance of 5052 aluminum bar?
The following are the various tolerances for different forms of 5052 aluminum alloy; they are:
- Round pull rods – tolerance range is between 0.3 and 2.5 mm.
- Square pull rods - tolerance values range from 0.3 to 1.7 mm.
- Flat steel – Tolerance values range from 0.35 to 1.4 mm.
- Cold rolled sheet - tolerance values range from 0.03 to 0.22 mm.
3.5052 aluminum bar price
5052 aluminum bar price = (LME ingot price + processing fee) × weight + packaging fee + transportation fee
Please contact the sales staff to inquire about the price and processing fee per ton of various specifications of aluminum bars. The processing fee of 5052 aluminum bars of different sizes may vary greatly, and we will provide you with the best quotation.
4.How to choose 5052 aluminum rod supplier/stockist?
When choosing a 5052 aluminum bar supplier, it is important to consider several factors to ensure you receive high-quality material and reliable service.
- Customized service: MASTAR can provide customized service according to customer needs. You only need to inform the length, quantity, surface finish, cutting, bending, color coating, end use and other special requirements.
- Competitive Price: Our products are priced competitively and we offer reasonable discounts for large quantities, giving you better prices and quality service.
- After-sales support: We provide fast after-sales support to ensure that you get timely help and support when using our products.
- Fast Delivery: We have abundant inventory to ensure fast shipment of any product, saving time for your project.
| MASTAR 5052 aluminum rod partial stock hot selling products | |
| 5052 aluminum cold finish round bars | Aluminum 5052 cold rolled round bar |
| Astm b211 aluminum 5052 cold drawn bars | Aluminum 5052 pump shaft quality bar |
| Ams 4114 aluminum 5052 round bar | Aluminium 5052A threaded bar |
| Aluminum alloy 5052 hot finish bar | 5052a aluminium forged bar |
| 5052 aluminium half round bar | Aluminum alloy5052A extruded rod |
| 5052 aluminum hot rolled round bar | |
5.MASTAR 5052 aluminum rod packaging
- Plastic or kraft paper packaging with moisture-proof desiccant inside.
- Mounted on wooden pallets, reinforced with steel straps and supplied with fumigation certificate.
- Meets GB/T3199 standard requirements.
- Packaging can be customized according to other customer requirements.
6.MASTAR 5052 aluminum rod product quality assurance
- 5052 There shall be no cracks, bubbles or corrosion spots on the surface of round bars, square bars and hexagonal bars.
- 5052 The surface of round bars, square bars or hexagonal bars shall not have deep scratches, wear, dents or straightening marks exceeding the tolerance range.
- Documents we provide include - Certificate of Origin, Invoice and PL certified by Chamber of Commerce, Test Certificate of Conformity and other test reports (as per client's requirement).
- Full traceability of 5052 Aluminium Bars and Strips – The bars will be fully marked and the details can be linked to the test certificates.
MASTAR 5052 aluminum bar stock size reference table
Below are some of the stock sizes of MASTAR's 5052 aluminum bars. If you can't find the product that suits your needs, you can click to communicate with our sales staff about the specific product. All lengths can be cut.Quick Quote
| Diameter (inch) | Diameter (Metric) | Weight (KG/Metre) | Availability |
| 3/8" | (9.53mm) | 0.202 | Available |
| 1./2" | (12.7 mm) | 0.355 | Available |
| 5/8" | (15.88 mm) | 0.561 | Available |
| 3/4" | (19.05 mm) | 0.807 | Available |
| 7/8" | (22.23 mm) | 1.097 | Available |
| 1" | (25.4 mm) | 1.419 | Available |
| 1.1/8" | (28.58 mm) | 1.816 | Available |
| 1.1/4" | (31.75 mm) | 2.241 | Available |
| 1.3/8" | (34.93 mm) | 2.690 | Available |
| 1.1/2" | (38.1 mm) | 3.226 | Available |
| 1.5/8" | (41.28 mm) | 3.747 | Available |
| 1.3/4" | (44.45 mm) | 4.360 | Available |
| 2" | (50.8 mm) | 5.675 | Available |
| 2.1/4" | (57.15 mm) | 7.190 | Available |
| 2.1/2" | (63.5 mm) | 8.867 | Available |
| 2.3/4" | (69.85 mm) | 10.730 | Available |
| 3" | (76.2 mm) | 12.769 | Available |
| 3.1/4" | (82.5 mm) | 14.986 | Available |
| 3.1/2" | (88.9 mm) | 17.380 | Available |
| 3.3/4" | (95.25 mm) | 20.165 | Available |
| 4" | (101.6 mm) | 22.700 | Available |
| 4.1/4" | (107.95 mm) | 25.627 | Available |
| 4.1/2" | (114.3 mm) | 28.730 | Available |
| 5" | (127 mm) | 35.469 | Available |
| 5.1/4" | (133.35 mm) | 39.105 | Available |
| 5.1/2" | (139.7 mm) | 42.994 | Available |
| 6" | (152.4 mm) | 51.076 | Available |
| 6.1/2" | (165.1 mm) | 59.943 | Available |
| 7" | (177.8 mm) | 69.650 | Available |
| 8 " | (203.2 mm) | 90.802 | Available |
| 9" | (228.6 mm) | 115.120 | Available |
| 10" | (254 mm) | 140.065 | Available |
